Máquina de roteador CNC turbo LUNYEE 4040, fresadora de gravação de 3 eixos com trilho linear totalmente metálico de 500 W

Venda Flash da Black Friday!

00 d

00 h

00 m

$748.00 ~~$1,099.99~~

32% de desconto

Frete calculado na finalização da compra.

Modelo: Eixo de 500 W

Eixo de 500 W Eixo de 500 W + Laser de 5,5 W Eixo de 500 W + Laser de 10 W

Variantes do produto

Quantidade:

$748.00

Eixo de 500 W

Pagamento e segurança

Ver detalhes

Durable All-Metal Construction

The Lunyee 4040 Turbo CNC machine features an all-metal construction with dual guide rails and a lead screw system, significantly enhancing engraving precision and overall strength while reducing noise during operation

Efficient Transmission System

The X and Y axes adopt the transmission method of φ12 optical axis guide + T10 lead screw, while the Z axis adopts the transmission method of φ12 optical axis + T10 lead screw. This 3 axis CNC router machine ensures smooth movement and high positioning accuracy, providing a reliable foundation for various machining tasks.

Strong Power

The LUNYEE 4040 CNC engraving machine is equipped with Nema 23 stepper motors and a 500W spindle motor, reaching a maximum speed of 12,000 RPM. It maintains excellent performance even during high-speed machining.

Easy Setup

The pre-assembled X, Y, and Z axis modules, along with pre-wired connections, significantly reduce assembly time, allowing you to start your engraving projects sooner with this router engraving machine.

Upgraded Z-Axis & Aluminum T-Slot Worktable

The new Z-axis reduces vibration and improves engraving precision, enhancing engraving stability by 80%. The durable aluminum T-slot worktable helps secure materials during CNC machining or laser engraving. This Lunyee 4040 Turbo CNC supports cutting and engraving various irregularly shaped or sized materials, such as wood, plastic, and soft metals. With a working area of 400mm x 300mm x 110mm, it is ideal for small to medium-sized projects.

Wide Compatibility

The LUNYEE 4040 Turbo 3 axis CNC router machine supports multi-mode switching and interchangeable spindle clamps. It offers 52mm and 65mm spindle clamps, allowing seamless switching from spindle to laser. Additionally, the Z-axis is equipped with multiple mounting holes to accommodate spindle clamps of various sizes, including 52mm, 65mm, 69mm, and 80mm.

GRBL-Based Control Box & Enhanced Chassis Design

ThThe power supply and control board are integrated into the control box, saving space, improving heat dissipation efficiency and safety, and making maintenance more convenient. This enhances overall performance and user experience. With the GRBL-based control board, the CNC engraving machine can be easily operated via USB using software like Fusion360 or Universal Gcode Sender. The robust and improved chassis design ensures long-lasting and reliable performance for this router engraving machine.

What are the reviews about 4040 Turbo CNC Router?

Premier projet LUNYEE 4040 TURBO : Une tirelire Taylor swift!

Pour découvrir la cnc de bureau 4040 TURBO de chez LUNYEE, je fabrique une demande spéciale de ma fille : Une tirelire inspirée par Taylor Swift!

Specifications

Model Name	LUNYEE 4040 Turbo
Work Area	400 x 400 x 110mm (15.75 x 15.75 x 4.33 inch)
Overall Dimensions	584 x 560 x 537mm (23 x 22 x 21.1 inch)
Control Board Compatibility	4-axis 5.0 GRBL 1.1f
MCU	32-Bit
Max Speed	5000mm/min
Control Software	Software Based on GRBL Firmware, e.g. Fusion360, Easel, Candle, UGS, LaserGRBL, LightBurn
Body Material	Aluminum Alloy & Carbon Steel
Accuracy	±0.1mm
Motion System	Optical Axis Guides：X, Y, Z Lead screws：X, Y, Z
Spindle Motor	500W Spindle, 1.5kw-2.2kw Water Cooled Spindle Motor (Optional)
Stepper Motor	NEMA 23, Stepper Motor
Safety	XYZ Limit Switch & Emergency Stop Switch
Power Supply	AC110/230V (Switch Power)
Net Weight	37kg (81 lb)

Support:

Email Support

One-year Warranty For Free

Compatible with GRBL-Base CAM/CNC Software
